30-150mm Motorized Zoom Lenses for C Mount Security Cameras Featured Image
  • 30-150mm Motorized Zoom Lenses for C Mount Security Cameras

Motorized zoom Lenses

Brief Description:

30-150mm Motorized Zoom Lenses for C Mount Security Cameras

  • Motorized Zoom Lens for Security Application
  • Mega Pixels
  • C/CS Mount Lens


Products

Product Detail

Product Tags

Model Sensor Format Focal Length(mm) FOV (H*V*D) TTL(mm) IR Filter Aperture Mount Unit Price
cz cz cz cz cz cz cz cz cz
1" 30~150mm 20MP P-Iris Motorized Zoom Lens
PDF Drawing

Model

CH195A

Type

Motor Lens

Relative Ill.

>45%(W),>40%(T)

Resolution

20MP

Chief Ray Angle

<3.0°

Image Format

1″

M.O.D

3m(W)~5m(T)

Image Circle

ф16mm(MAX)

Mount Type

C-Mount

EFL

30~150mm

Dimension Figure

W85*H80*L144.8mm

MBF

13.526mm

Coating Range

400-900nm

F/NO.

F2.5(W)~2.7(T)

IR Correction

YES

Flange BFL

17.526mm

Weight

/

BFL（O)

12.02mm

Iris Operation

P-Iris

For Sensor

1.1″

Zoom Operation

Motorized

F.O.V

Horizontal

26.5-7.1°

Focus Operation

Motorized

Vertical

18.1-4.9°

Operating Temperature

-20°~+85°

Diagonal

32.3-8.5°

Storage Temperature

-20°~+85°

OPT Distortion

<-4.3%



Features of motorized zoom lenses:

● What a motorized zoom lens is: Motorized zoom lens allows you to remotely adjust your camera on your phone or NVR. With optical zoom, you’ll never lose detail when zooming in or out. No need of handling the lens, so no more opening up the camera to adjust it.

● Mechanical interface : C mount and CS mount. For C mount lenses, they can be connected to CS mount camera using a CS-C mount adapter.

● Application fields : These lenses are ideal for CCTV security cameras.
