Products
|
Model |
CH608A |
|||
|
Type |
Machine Vision Lens |
M.O.D |
0.1m |
|
|
EFL |
8mm |
Mount Type |
C/CS |
|
|
F.NO |
F1.8~16 |
Dimension Figure |
ф52.0*L53.0mm |
|
|
Resolution |
10MP |
Filter Size |
M67*P0.75 |
|
|
Image Format |
1″ |
Weight |
221g |
|
| BFL(M) |
17.53 |
Iris Operation |
Manual |
|
|
F.O.V |
Horizontal |
77.1° |
Zoom Operation |
Fixed |
|
Vertical |
61.8° |
Focus Operation |
Manual |
|
|
Diagonal |
89.5° |
Operating Temperature |
-20°~+85° |
|
|
TV Distortion |
<-5% |
Storage Temperature |
-20°~+85° |
|
This product was successfully added to cart!
1″ Machine Vision Lenses
Products
Product Detail
Product Tags
| Model | Sensor Format | Focal Length(mm) | FOV (H*V*D) | TTL(mm) | IR Filter | Aperture | Mount | Unit Price | ||
|---|---|---|---|---|---|---|---|---|---|---|
| MORE+LESS- | CH608A | 1" | 8 | 77.1°*61.8°*89.5° | / | / | F1.8-16 | C/CS | $99Request Quote |
|
| MORE+LESS- | CH609A | 1" | 12 | 56.3°*43.5°*67.5° | / | / | F2.0-16 | C/CS | Request Quote |
|
| MORE+LESS- | CH610A | 1" | 16 | 43.6°*33.4°*53.1° | / | / | F1.4-16 | C/CS | $55Request Quote |
|
| MORE+LESS- | CH611A | 1" | 25 | 28.9°*21.8° | / | / | F1.4-16 | C/CS | $55Request Quote |
|
| MORE+LESS- | CH612A | 1" | 35 | 19.44°*14.7°*24° | / | / | F1.4-16 | C/CS | $55Request Quote |
|
| MORE+LESS- | CH613B | 1" | 50 | 13.9°*10.4° | / | No | F2.5-22 | C/CS | $55Request Quote |
|
| MORE+LESS- | CH614E | 1" | 75 | 9.8°*7.4°*12.2° | / | / | F2.8 | C | $55Request Quote |
|
| MORE+LESS- | CH615A | 1" | 100 | 7.2°*5.5°*9.7° | / | / | F3.5-32 | C/CS | $60Request Quote |
|
1″ series 10MP machine vision lenses is designed for 1″ image sensor, such as AR1011HS, IMX255, IMX267 etc. The IMX267 is a diagonal 16.1mm CMOS active pixel type solid-state image sensor with a square pixel array and 8.95M effective pixels. Pixel size 3.45μm(H) x 3.45μm(V). This chip opereates with analog 3.3V, digital 1.2V, and has low power consumption. High sensitivity, low dark current and low PLS characteristics are achieved. (applications: FA cameras, ITS cameras)
ChuangAn Optics 1″ 10MP machine vision lenses features:
> Large image format
> High resolution
> Low distortion
> Focal length covering 8mm ~ 100mm.
> Competitive price
This series machine vision lenses can be used in consumer electronics inspection: Such as PC FPC terminal line inspection, mobile phone SIM card slot character reading, earphone appearance, mobile phone screen broken screen, mobile phone chip defect, mobile phone solder joint slot inspection, display inspection.
-
